Schematic diagram — photography not yet supplied for this model.
| 1 | Payload (Kgs) | 533 Kgs |
| 2 | GVW / GCW (Kgs) | 975 kg |
| 3 | Fuel Tank (Litres) | 40 Ltr |
Piaggio Ape Xtra
On requestNewICEThree-wheeler
Available variants
- CNG/5 ft ( CNG )
- Diesel/ 6 ft ( Diesel )
- LPG/ 5.5 ft ( LPG )
Pricing
On request
Send an enquiry with the quantity and your destination country — our team confirms availability, price and shipping.
Send enquiryThe Piaggio Ape Xtra is an LPG goods-carrying three-wheeler with a 533 Kgs payload. Indicative ex-showroom price in India starts from Rs. 2,45,000.
Performance
- Fuel Tank (Litres)
- 40 Ltr
- Engine
- 4-stroke, 2-valve, Otto Cycle 305.2 Cc lpg engine
- Fuel Type
- LPG
- Emission Norms
- BS-VI
- Max Torque
- 23.5 Nm
- Gradeability (%)
- 22.2 %
- Max Speed (km/h)
- 56
- Turning Radius (mm)
- 4500
- Engine Displacement (cm3)
- 210
- Product Type
- L3N (Low Speed Goods Carrier)
- Carrier Type
- Goods Carrier
Dimensions
- Overall Length (mm)
- 2930
- Overall Width (mm)
- 1490
- Overall Height (mm)
- 2350
- Ground Clearance (mm)
- 245
- Wheelbase (mm)
- 2100
- Axle Configuration
- 3x3
- Size (Cu. M)
- 5.5 ft
Transmission & Loading Capacity
- Transmission
- Automatic
- Payload (Kgs)
- 533 Kgs
- GVW / GCW (Kgs)
- 975 kg
- Kerb Weight (Kgs)
- 250
- Gear Box
- 1 Forward + 1 Reverse
- Clutch
- Multi Disc Wet Type
- Power Steering
- No
Features
- Steering
- Handle bar type
- A/C
- No
- Cruise Control
- No
- Navigation System
- No
- Telematics
- No
- Tiltable Steering
- No
- Arm-rest
- No
- Seat Type
- Standard
- Driver Information Display
- Yes
- Adjustable Driver Seat
- No
- Seating Capacity
- Driver Only
- Tubeless Tyres
- Yes
- Seat Belts
- Yes
- Hill Hold
- No
Brakes & Suspension
- Brakes
- Drum Brakes
- Front Suspension
- Independent Suspension
- Rear Suspension
- Leaf Spring Suspension
- Parking Brakes
- Yes
Body Option & Cabin Type
- Chassis Type
- Chassis with Cabin
- Body Option
- Customizable body
- Cabin Type
- Day Cabin
- Tiltable Cabin
- No
Tyres
- Number of Tyre
- 3
- Rear Tyre
- 4.50x10-8 PR
- Front Tyre
- 4.50x10-8 PR
Others
- Chassis
- Yes
- Fog Lights
- No
Sourced from the Indian domestic market; specification and availability confirmed with DAX at enquiry.
