| 1 | Battery Capacity | 8.86 kWh |
| 2 | Max Power | 11 kW |
| 3 | Payload (Kgs) | 457 Kgs |
| 4 | GVW / GCW (Kgs) | 998 kg |
| 5 | Range | 156 km |
| 6 | Charging Time | 3 Hrs 10 Min |
TVS King Kargo HD EV
On requestNewEVThree-wheeler
Available variants
- 2310/FSD ( Electric )
- 2310/Container ( Electric )
- 2310/Platform ( Electric )
- 2310/CBC ( Electric )
Pricing
On request
Send an enquiry with the quantity and your destination country — our team confirms availability, price and shipping.
Send enquiryThe TVS King Kargo HD EV is an electric goods-carrying three-wheeler with a 8.86 kWh battery, 11 kW of peak power and a 457 Kgs payload.
Performance
- Max Power
- 11 kW
- Fuel Type
- Electric
- Max Torque
- 40 Nm
- Gradeability (%)
- 28.7 %
- Max Speed (km/h)
- 60
- Turning Radius (mm)
- 3420
- Range
- 156 km
- Battery Capacity
- 8.86 kWh
- Type of Motor
- PMSM
- Carrier Type
- Goods Carrier
- Product Type
- L5N (High Speed Goods Carrier)
Charging
- Charging Time
- 3 Hrs 10 Min
Dimensions
- Overall Length (mm)
- 3565
- Overall Width (mm)
- 1530
- Overall Height (mm)
- 1860
- Ground Clearance (mm)
- 235
- Wheelbase (mm)
- 2310
- Loading Length {mm}
- 1828
- Loading Width {mm}
- 1219
- Loading Height {mm}
- 305
Transmission & Loading Capacity
- Transmission
- Automatic
- Payload (Kgs)
- 457 Kgs
- GVW / GCW (Kgs)
- 998 kg
- Kerb Weight (Kgs)
- 541
- Gear Box
- Twin Speed
- Power Steering
- No
Features
- Steering
- Handle bar type
- A/C
- No
- Cruise Control
- No
- Navigation System
- Yes
- Telematics
- No
- Tiltable Steering
- No
- Arm-rest
- No
- Seat Type
- Standard
- Driver Information Display
- Yes
- Adjustable Driver Seat
- No
- Seating Capacity
- Driver Only
- Tubeless Tyres
- Yes
- Seat Belts
- No
- Hill Hold
- No
Brakes & Suspension
- Brakes
- Hydraulic Drum Brakes
- Front Suspension
- Single Fork Leading Link Coil Spring
- Rear Suspension
- Leaf Spring with Hydraulic Damper (Parabolic type)
- ABS
- No
Body Option & Cabin Type
- Chassis Type
- Chassis with Cabin
- Body Option
- Deck Body
- Cabin Type
- Day Cabin
- Tiltable Cabin
- No
Tyres
- Number of Tyre
- 3
- Rear Tyre
- 130/80R12 90F Radial
- Front Tyre
- 130/80R12 90F Radial
Others
- Chassis
- Yes
- Fog Lights
- No
Sourced from the Indian domestic market; specification and availability confirmed with DAX at enquiry.
