| 1 | Battery Capacity | 8 kWh |
| 2 | Max Power | 5.44 kW |
| 3 | Seating Capacity | D+3 Passenger |
| 4 | GVW / GCW (Kgs) | 713 kg |
| 5 | Range | 150 km |
| 6 | Charging Time | 3 hours 45 minutes |
Piaggio Ape E City FX Max
On requestNewEVThree-wheeler
Available variants
- 3-Seater/1920/Electric ( Electric )
Pricing
On request
Send an enquiry with the quantity and your destination country — our team confirms availability, price and shipping.
Send enquiryThe Piaggio Ape E City FX Max is an electric passenger three-wheeler with a 8 kWh battery and 5.44 kW of peak power.
Performance
- Max Power
- 5.44 kW
- Engine
- Advanced telematics 2.0
- Fuel Type
- Electric
- Max Torque
- 29 Nm
- Gradeability (%)
- 20 %
- Max Speed (km/h)
- 50
- Turning Radius (mm)
- 4200
- Range
- 150 km
- Battery Capacity
- 8 kWh
- Type of Motor
- Advanced telematics 2.0
- Product Type
- L5M (High Speed Passenger Carrier)
- Carrier Type
- Passenger Carrier
Charging
- Charging Time
- 3 hours 45 minutes
Dimensions
- Overall Length (mm)
- 2700
- Overall Width (mm)
- 1370
- Overall Height (mm)
- 1725
- Ground Clearance (mm)
- 163
- Wheelbase (mm)
- 1920
- Axle Configuration
- 3x3
Transmission & Loading Capacity
- Transmission
- PT Gear with Differential (Integrant)
- GVW / GCW (Kgs)
- 713 kg
- Kerb Weight (Kgs)
- 413
- Gear Box
- 1 Forward + 1 Reverse
- Power Steering
- No
Features
- Steering
- Handle bar type
- A/C
- No
- Cruise Control
- No
- Navigation System
- No
- Telematics
- No
- Tiltable Steering
- No
- Arm-rest
- No
- Seat Type
- Standard
- Driver Information Display
- Yes
- Adjustable Driver Seat
- No
- Seating Capacity
- D+3 Passenger
- Tubeless Tyres
- Yes
- Seat Belts
- No
- Hill Hold
- No
Brakes & Suspension
- Brakes
- Drum Brake hydraulically actuated internal expanding shoe type
- Front Suspension
- Loading arm, constant rate coil spring with hydraulic dampaner
- Rear Suspension
- Semi trailing arm, rubber spring with hydraulic dampaner
- ABS
- No
- Parking Brakes
- Yes
Body Option & Cabin Type
- Chassis Type
- Chassis with Cabin
- Body Option
- Fully Built
- Cabin Type
- Day Cabin
- Tiltable Cabin
- No
Tyres
- Number of Tyre
- 3
- Rear Tyre
- 120/80 R 12
- Front Tyre
- 120/80 R 12
Others
- Chassis
- Yes
- Battery(Volts)
- 51.2 V
Sourced from the Indian domestic market; specification and availability confirmed with DAX at enquiry.
